LockSecure
AI Smart Door Lock based on nRF9160
LTE-M smart deadbolt with integrated edge facial recognition and tamper alerts.
Face Auth Time
<1.2s
Battery Life
14 Months
LockSecure
Client
A property security company requiring a retrofit cellular door lock that works in buildings without Wi-Fi and provides real-time access logging for landlords.
Challenge
Integrating a camera, motor, and LTE modem into a standard 50mm door lock form factor while achieving 1-year battery life on 4xAA batteries.
Product Concept & Architecture
The Nordic nRF9160 SiP provides both LTE-M connectivity and application processing. A GC032A IR camera captures visitor images. A miniature brushless DC gear motor drives the deadbolt via a custom planetary gearbox (100:1 reduction).
Engineering Solution
The firmware on Zephyr RTOS implements a duty-cycled wake schedule: the camera and face recognition subsystem activate only when the capacitive touch keypad or doorbell button is pressed. Face recognition uses a quantized MobileNet model running on the nRF9160's Cortex-M33. LTE-M data transmission is batched — all access logs upload once daily unless a tamper event is detected, triggering immediate alert.
Result
Sub-1.2 second face authentication. Zero false accepts in 5,000 trials. 14-month battery life with 20 access events per day.
Deep Tech FAQ
What makes the AI Smart Door Lock based on nRF9160 unique?+
The AI Smart Door Lock based on nRF9160 leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded SoftwareRF Design
Core Technologies
LTE-M/NB-IoTComputer VisionRTOS
Silicon & Vendors
NordicSTMicroelectronics
