ChefAI
Smart Kitchen Display based on Allwinner A133
Voice-first recipe assistant running Android AOSP.
Vision FPS
30 FPS
Thermal Max
45°C
ChefAI
Plan A — Quick Facts
Processor
Allwinner A133 Quad-Core
Audio Input
4-Mic Linear Array with DSP
Display
10.1-inch IPS, Optically Bonded
Environmental
IP65 Front Panel (Steam/Grease Proof)
Client
A smart home appliance manufacturer creating an under-cabinet kitchen display for recipes and timer management.
Challenge
Creating a highly durable, steam-proof, and grease-resistant display unit with reliable far-field voice recognition for hands-free cooking.
Product Concept & Architecture
The Allwinner A133 (Quad-core Cortex-A53) was chosen for its excellent cost-to-performance ratio for 1080p UI rendering. It connects to a 10.1-inch IPS display and a 4-mic linear array.
Engineering Solution
The hardware features a fully sealed glass front panel with optical bonding to prevent internal condensation from boiling pots. We integrated a third-party audio DSP algorithm directly into the Android ALSA audioHAL to achieve far-field voice wake-up, even with the sound of frying pans or running water in the background.
Result
Voice wake-up rate > 92% in 70dB kitchen noise environments. IP65 rated front panel. Smooth UI performance for video recipes.
Project Profile
Services Delivered
OS PortingHardware Design
Core Technologies
Android AOSPEmbedded LinuxNPU Acceleration
Silicon & Vendors
MediaTekRockchipQuectelAllwinner
