Wearables
BandAI
AI Smart Bracelet based on DA14697
28-day battery smart band with edge gesture recognition and automatic activity detection.
Battery Life
28 Days
Gesture Accuracy
95%
BandAI
Client
A consumer electronics company creating a minimal-interaction smart band focused on extended battery life and intuitive gesture navigation.
Challenge
Achieving 28-day battery life while supporting an always-on AMOLED display and continuous IMU-based gesture recognition.
Product Concept & Architecture
The Dialog DA14697 BLE SoC was selected for industry-leading power efficiency. A BHI360 integrated IMU + sensor hub offloads motion processing from the main CPU. A 1.1-inch round AMOLED runs at 1Hz always-on. A 250mAh Li-Po battery fits in the 12mm-thick band module.
Engineering Solution
The DA14697's dedicated Sensor Node Controller continuously processes BHI360 data at 200Hz while the main Cortex-M33 sleeps. A TinyML gesture model (hand-wave to dismiss, wrist-twist to scroll, double-tap to select) runs entirely on the Sensor Node using 4KB of memory.
Result
28-day real-world battery life. 95% gesture recognition accuracy. Always-on display consumes only 8µA average.
Deep Tech FAQ
What makes the AI Smart Bracelet based on DA14697 unique?+
The AI Smart Bracelet based on DA14697 leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded Software
Core Technologies
BLETinyMLRTOS
Silicon & Vendors
Dialog SemiconductorBosch
