FlashCard
AI Smart Card Reader based on Jieli AC692N
Battery-operated card reader that recognizes NFC-enabled flashcards and plays native-pronunciation audio in 8 languages.
Card Detection
100ms
Audio Languages
8
FlashCard
Client
An early childhood education company creating a screen-free language learning system using physical flashcards with audio output.
Challenge
Developing a robust, child-proof card reader that instantly recognizes NFC-tagged cards (even when inserted upside-down or at an angle) and plays high-quality audio in 8 languages.
Product Concept & Architecture
The Jieli AC692N audio SoC handles NFC polling and audio decoding. An RC522 NFC module reads passive tags embedded in each flashcard.
Engineering Solution
We implemented a custom antenna geometry that provides 40mm read range, ensuring detection regardless of insertion angle. When a card is detected, the 7-byte UID is decrypted to determine the language and word. Audio is decoded via the AC692N's hardware MP3 decoder for instant playback (<100ms).
Result
0% card detection failure rate in child testing (2-6 year olds). 100ms audio playback latency.
Deep Tech FAQ
What makes the AI Smart Card Reader based on Jieli AC692N unique?+
The AI Smart Card Reader based on Jieli AC692N leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded Software
Core Technologies
Wi-Fi/BluetoothTinyMLRTOS
Silicon & Vendors
JieliNXP
