Smart Home
BrewSmart
AI Smart Coffee Brewer powered by ESP32-C6
Learns your perfect cup: temperature profile, bloom time, and grind optimization.
Temp Stability
±0.3°C
Brew Time
3:30 typical
BrewSmart
Client
A specialty coffee equipment manufacturer seeking a connected espresso machine with automated recipe tuning.
Challenge
Achieving water temperature stability within ±0.5°C during active extraction while running real-time pressure profiling, all within a 150mm diameter boiler housing.
Product Concept & Architecture
The ESP32-C6 with its Wi-Fi 6 and 802.11ax connectivity was selected as the main controller. A MAX31850 thermocouple amplifier reads boiler temperature, while a pressure transducer monitors the group head. A MOSFET-driven 1200W heater element provides rapid heat-up.
Engineering Solution
The firmware implements a cascaded PID loop on the ESP32-C6: an outer loop controls brew water temperature, and an inner loop modulates the vibration pump PWM for pressure profiling. User feedback (sour/bitter ratings) trains a local Bayesian optimizer that adjusts temperature and pressure parameters per coffee bean profile. Brew logs sync to cloud via Matter protocol for smart home integration.
Result
Repeatable extraction within 0.3°C and 0.2 bar. Over 200 brew profiles crowd-sourced and shared via the companion app. Winner of 2025 SCA Best New Product award.
Deep Tech FAQ
What makes the AI Smart Coffee Brewer powered by ESP32-C6 unique?+
The AI Smart Coffee Brewer powered by ESP32-C6 leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded Software
Core Technologies
Wi-Fi/BluetoothRTOSTinyML
Silicon & Vendors
EspressifTI
