Smart Home
SmartWindow
AI Smart Curtain Controller powered by ESP32-C3
Energy-harvesting smart curtain controller that learns household wake/sleep patterns.
Battery Life
18+ Months
Sleep Current
5 µA
SmartWindow
Client
A smart home automation company looking for a low-power, retrofit-friendly curtain motor controller with smart home ecosystem integration.
Challenge
Designing a motor controller that fits inside a standard curtain rod (28mm diameter), operates silently, and runs for months on a single charge while supporting real-time cloud scheduling.
Product Concept & Architecture
We selected the ESP32-C3 for its RISC-V architecture with excellent power management features. The motor is driven by a TMC2209 stepper driver in stealthChop mode. A small 6V solar panel trickle-charges a 2000mAh Li-Po battery.
Engineering Solution
Built on ESP-IDF with FreeRTOS. The system uses a custom adaptive sleep scheduler: if the curtain hasn't moved in 4 hours, it increases the Wi-Fi beacon interval to 300 seconds. A built-in ambient light sensor (BH1750) enables sunrise-aligned gradual opening over 30 minutes to simulate natural waking. Over-the-air firmware updates are delivered via ESP-OTA.
Result
Installation in 15 minutes without wiring. Silent operation at <30dB. Battery lasts 18+ months in typical use. Alexa/Google Home certified.
Deep Tech FAQ
What makes the AI Smart Curtain Controller powered by ESP32-C3 unique?+
The AI Smart Curtain Controller powered by ESP32-C3 leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded Software
Core Technologies
Wi-Fi/BluetoothTinyMLRTOS
Silicon & Vendors
EspressifTexas Instruments
