Expert PCB design services covering schematic capture, stack-up planning, signal integrity analysis, and DFM optimization.

High-speed digital design (DDR5, PCIe Gen5, 400G Ethernet)
Mixed-signal and precision analog topologies
Multi-band RF and antenna array integration
Rigid, flex, and complex rigid-flex fabrics
HDI with stacked microvias and laser-drilled blind vias
Time-domain and frequency-domain SI/PI analysis
Every micrometer of copper is an opportunity for signal optimization. We treat PCB layout as a multidimensional physics simulation from the first via.
Multi-layer, HDI, Flex-Rigid — delivering measurable impact through deep technical expertise.
From discrete consulting engagements to full turnkey delivery, we adapt to your program's specific needs and timeline.
ChipTalk's PCB design team has taped out over 200 unique board designs across automotive, aerospace, medical, and consumer verticals. We treat every board as a high-speed, high-reliability challenge regardless of layer count, and our signal-integrity-first workflow catches impedance discontinuities and crosstalk violations before the first prototype is fabbed.
Designed a 28-layer PCIe Gen5 add-in card with 112 Gbps PAM4 SerDes, managing 30+ differential pairs with <1 dB insertion loss variance across the link.
Developed a 16-layer mixed-signal board with 64-channel analog front-end, achieving 88 dB SNR and passing IEC 60601 EMI compliance on the first pass.
Our DFM-integrated workflow—including IPC-6012 class 3 compliance, automated DFM rule checks, and panel-optimized stack-ups—consistently delivers first-pass prototype success rates above 85%.
