Full-Stack Embodied AI Plush Toy Solution
Herzen Berühren mit Plüsch
Spielzeug eine Stimme Geben
Branchenführende Full-Stack-Lösung für smarte AI-Plüschtiere. Vom ultrakompakten Sicherheits-Hardwarekern (≤38°C / EN71 Spielzeugsicherheit) bis zum Vollduplex-Sprachgehirn und White-Label-App.
45 DaysFast Turnkey Prototyping
<800msFull-Duplex Streaming Voice
≤38°CSurface Temperature Safe
100%EN71 / GB6675 Compliant
AI 电子吧唧 · 1:1 实体拟真机AMOLED · 60fps Live2D
78 BPM
SILICON & HARDWARE TEARDOWN
Chipset Hardware Teardown & Reference BOM
Capsule-grade safety micro-core architecture for toy IPs, engineered to maintain ≤38°C surface temperature with sub-800ms full-duplex voice conversational AI.
System Architecture
Edge-Cloud Streaming Audio Pipeline (Cool-Running Safety Core)
Bus / Pipeline Latency
<800ms Full-Duplex Conversational Barge-in Latency
Power Envelope
Active: 95mA / Standby: 18μA (Surface Temp ≤38°C)
Dual-Core Audio DSP/MCUJieli (杰理) / Espressif
JL7016 / ESP32-S3
Dual-core Audio DSP @ 160MHz, Hardware VAD Wakeup, OPUS Codec
Ultra-low heat dissipation package meeting GB6675/EN71 safety guidelines
Dual MEMS Mic ArrayKnowles (楼氏)
SPH0645LM4H-B
Digital I2S Interface, 65dB SNR, Low-Power Sleep Mode
Sub-800ms barge-in voice interruption & near-field dereverberation
6-Axis IMU SensorBosch Sensortec
BMI270
16-bit 3-axis Accel + Gyro, 685μA Typical Current
Recognizes hugging, shaking, lifting, and drop gesture interactions
Thermal Safety PMICTexas Instruments
BQ24040
1A Single-Cell Li-ion Charger with Dual NTC Over-temp Protections
Hardware protection against over-charging, short-circuit, and thermal runaway
Production Compliance & Verification Standards
EN71-1/2/3ASTM F963GB6675RoHS
Transformation Strategy
Break Free from Commodity Margins to High-Value Embodied AI
Traditional toy OEMs suffer from razor-thin margins. Building in-house smart toys faces acoustic, algorithmic, safety, and software chasms. ChipTalk LYAAI provides a turnkey leapfrog solution.
Traditional Toy Makers & Fragmented Suppliers
Sewing Expertise without Acoustics & Electronics
Haphazard hardware builds run hot (>42°C); rigid parts ruin plush softness and fail stringent EN71 / GB6675 toy certifications.
Rigid Cloud Dialogue with >3s Delays
Uninterruptible ping-pong turns with robotic TTS voices lack emotional memory; children and collectors abandon the toy within days.
No Companion App or Data Assets
Lack of software expertise loses customer touchpoints post-sale, eliminating subscription content and accessory cross-sell opportunities.
ChipTalk LYAAI Full-Stack Turnkey Empowerment
Capsule Safety Core with Soft Touch & Cool Operation
Ultra-compact capsule module (down to 38×28mm), surface temperature ≤38°C, flexible sensors seamlessly embedded, 1.5m drop-proof.
Sub-800ms Full-Duplex Voice with Empathetic Personas
Streaming sub-800ms latency allows natural user barge-in; proprietary emotion models craft charismatic personas that grow closer over time.
White-Label Companion App for Lifetime Value
Turnkey iOS/Android companion app with Bluetooth pairing, nearby toy radar, OTA persona updates, and recurring content subscriptions.
Full-Stack Architecture
ChipTalk Turnkey AI Plush Hardware & Software Architecture
From custom silicon modules and acoustic noise reduction to streaming LLM voice brains and white-label apps, build an unassailable vertical moat.
Layer 01/Cloud Brain
Cloud Emotion Voice AI Brain
Persona libraries, contextual memory, external knowledge bases, and low-latency streaming orchestration.
Sub-800ms First Byte
Lifelike Character Voices
Natural Barge-in
Scenario Scripts
Layer 02/Hardware Core
Embedded Ultra-Compact Safety Core
Proprietary low-power SoC, dual-mic beamforming, toy-grade drop-proof capsule, and active thermal management.
38×28mm Form Factor
Surface Temp ≤38°C
1.5m Drop Resistance
Flexible Wiring
Layer 03/Mobile Experience
White-Label Companion App & Social Radar
Instant BLE pairing, persona customization, nearby friend discovery, and parental controls.
Instant Pairing
Proximity Toy Radar
Parental Dashboard
Continuous OTA
Layer 04/Ecosystem & Compliance
Productivity Extensibility & Global Toy Certifications
Integration with Openclaw / Hermes agent workflows, fully certified for EN71 / GB6675 / FCC standards.
Calendar / Notes Readout
EN71 Direct Pass
GB6675 Certified
45-Day Mass Production
Core Capabilities
Four Pillars Fueling Viral, Engaging AI Plush Companions
Overcoming the twin dilemmas of “smart toys becoming rigid & hot” and “robotic conversations” across hardware, models, and experience.
01
Toy-Grade Ultra-Micro Core
Plush softness preserved with zero overheating worries
Capsule-level integration with optimized thermal dissipation keeps the surface temperature safely under 38°C. Encased in shock-absorbing silicone to survive heavy drops.
12mm
Module Thickness
≤38°C
Surface Temperature
7-10 Days
Standby Battery Life
02
Full-Duplex Streaming Voice Brain
Natural barge-in and conversational empathy
Engineered with millisecond acoustic echo cancellation (AEC) and dual-mic beamforming. Users can interrupt at any moment, enjoying authentic emotional rapport.
<800ms
First Token Latency
3-5 Meters
Voice Pickup Range
50+ Options
Voice Personas
03
White-Label Companion App
Nearby friend radar transforming hardware into private communities
Production-ready iOS/Android codebase supporting BLE discovery, persona tuning, and nearby companion toy networking to build sticky IP communities.
99.2%
Pairing Success
68%
Day-30 Retention
7 Days
Delivery Timeframe
04
Lifestyle to Productivity Extension
Openclaw / Hermes powered desk intelligence
Integrate with Openclaw / Hermes agents to convert plush companions into personal desk assistants: meeting notes, schedule alerts, and email summaries.
Openclaw / Hermes
Ecosystem
<1s
Alert Latency
Modular APIs
Extensibility
Engineered Specs
Industrial Core Hardware Specification Matrix
Three standardized hardware micro-core variants engineered for rapid customization from small bag charms to articulated animatronics.
LYA-C01
Compact Voice CoreMaximum Cost Efficiency
Dimensions:38 × 28 × 12 mm
Acoustics:Single mic noise canceling + 0.8W acoustic chamber, streaming full duplex
Connectivity:Wi-Fi 2.4GHz + BLE 5.0 Dual Mode
Battery & Runtime:500mAh Li-Po, 5-day standby
Sensors & Inputs:Tactile push button / vibration wake-up
Recommended Use:Small/medium plush dolls, keychain charms, promotional gift toys
LYA-C02
Emotional Flagship CoreFlagship Bestseller
Dimensions:42 × 32 × 14 mm
Acoustics:Dual-mic beamforming array + 1.2W acoustic bass chamber with barge-in support
Connectivity:Dual-band Wi-Fi + BLE 5.2 + Proximity Radar
Battery & Runtime:1200mAh explosion-proof battery, 7-10 days normal use
Sensors & Inputs:3-zone capacitive touch sensors, 6-axis IMU gravity sensor
Recommended Use:Mainstream 20-40cm plush toys, licensed IP companions, smart early education
LYA-M01
Mecha Action CoreArticulated Embodied AI
Dimensions:50 × 38 × 18 mm
Acoustics:Dual-mic stereo pickup + 2.0W high-volume stereo speaker
Connectivity:Dual-band Wi-Fi + BLE 5.3 + 2.4G proprietary link
Battery & Runtime:2000mAh dynamic battery, Type-C fast charging
Sensors & Inputs:4-channel servo driver interfaces + touch + head micro-switches
Recommended Use:Articulated mechanical plush, animatronic robotic pets, exhibition mascots
| Hardware Model | Dimensions | Acoustics | Connectivity | Battery & Runtime | Sensors & Inputs | Recommended Use | Action |
|---|---|---|---|---|---|---|---|
LYA-C01 Compact Voice Core Maximum Cost Efficiency | 38 × 28 × 12 mm | Single mic noise canceling + 0.8W acoustic chamber, streaming full duplex | Wi-Fi 2.4GHz + BLE 5.0 Dual Mode | 500mAh Li-Po, 5-day standby | Tactile push button / vibration wake-up | Small/medium plush dolls, keychain charms, promotional gift toys | |
LYA-C02 Emotional Flagship Core Flagship Bestseller | 42 × 32 × 14 mm | Dual-mic beamforming array + 1.2W acoustic bass chamber with barge-in support | Dual-band Wi-Fi + BLE 5.2 + Proximity Radar | 1200mAh explosion-proof battery, 7-10 days normal use | 3-zone capacitive touch sensors, 6-axis IMU gravity sensor | Mainstream 20-40cm plush toys, licensed IP companions, smart early education | |
LYA-M01 Mecha Action Core Articulated Embodied AI | 50 × 38 × 18 mm | Dual-mic stereo pickup + 2.0W high-volume stereo speaker | Dual-band Wi-Fi + BLE 5.3 + 2.4G proprietary link | 2000mAh dynamic battery, Type-C fast charging | 4-channel servo driver interfaces + touch + head micro-switches | Articulated mechanical plush, animatronic robotic pets, exhibition mascots |
Success Stories
Proven Track Record: From Commodity Price Wars to Viral Hits
Empowered leading IP creators and toy manufacturers to achieve massive increases in volume, pricing power, and community loyalty.
Designer Toy IPIP Viral Hit
Cyber Mecha Rabbit · Limited Edition Launch
Designer Toy IP
A prominent anime toy brand embedded the ChipTalk LYA-C02 core into a 25cm plush rabbit with a witty mecha persona. The initial 20,000 units sold out in 15 minutes, boosting unit price from $14 to $69.
15 Minutes
Sold Out Time
+460%
Price Premium
76%
30-Day Community Engagement
“ChipTalk full-duplex core transformed our display figurine into a living cyber companion fans talk to every night.”
Early Childhood EducationTop Educator Toy
Starlight Bear · The Empathetic Storyteller
Educational Companion
Co-developed with a leading early education brand, featuring green kid-safe LLM filters, habit coaching, and bedtime audio. Fully certified for EN71/GB6675 standards.
180,000+ Units
Annual Volume
94.8%
Parent Recommendation
100% Pass
Safety Compliance
“Kids cannot feel any hard electronics inside; it stays cool and safe for mothers to trust unconditionally.”
Emotional DecompressionWellness Companion
Warm Fluff Kitty · Desktop Desk Sanctuary
Adult Wellness
Tailored for young urban professionals seeking comfort. Features capacitive stroke sensing, soothing acoustics, and Openclaw schedule reminders.
38 Minutes
Daily Interaction
32%
Accessory Repurchase
50M+
Social Impressions
“Coming home from overtime and chatting with this warm kitty melts away the entire day’s exhaustion.”
Cooperation Models
Flexible B2B Commercial Engagement Models
Tailored collaboration models suited for traditional toy OEMs, global anime/gaming IP holders, and emerging smart hardware brands.
推荐选型方案
Turnkey ODM / OEM Solution
End-to-End DeliveryFrom electronic architecture, core manufacturing, plush sample prototyping, to global certifications and mass production, we handle everything turnkey.
适合: Plush toy brands and trading companies with established retail channels
标准交付物清单
Core module PCBA supply
Acoustic & structural tooling validation
EN71 / GB6675 certification audit
Full white-label mobile app
Core Module Licensing & PCBA Supply
Direct Module SupplyBulk supply of standardized LYA cores to your assembly facilities, complete with acoustic chamber guidelines and test fixtures.
适合: Large toy manufacturers with existing assembly plants and OEM factories
标准交付物清单
Standard LYA core batches
3D mechanical integration guides
Firmware flashing & QC test jigs
Hardware technical warranty
Cloud Voice Brain & White-Label App
Software & AI CloudFor partners with existing hardware lines, we provide our low-latency streaming voice engine, persona model training, and white-label mobile apps.
适合: IoT hardware teams and IP owners looking to add conversational AI
标准交付物清单
Streaming voice agent APIs
Custom voice persona model training
White-label iOS/Android source code
Dedicated analytics portal
ENGINEERING & DELIVERY FAQ
B2B Engineering & Turnkey Delivery FAQ
Addressing critical technical, customization, lead-time, and certification questions for hardware PMs and enterprise engineering directors.
ChipTalk.ai provides a comprehensive production-ready engineering package:
1. Complete Hardware Files: Altium / Cadence schematics (.SchDoc), 4-to-8 layer impedance-controlled PCB Gerber files, component Bill of Materials (BOM) with Tier 1 second-source designations, and pick-and-place coordinate files;
2. Source Firmware & BSP: Board Support Packages (Bare-metal / FreeRTOS / Zephyr), automated factory test-fixture (ATE) scripts, and flash programming tools;
3. Mechanical & Tooling: 1:1 3D CAD models (STEP/IGES), mold DFM analysis reports, and injection tooling guidelines;
4. Companion Software: White-label iOS/Android mobile companion apps (Flutter/React Native) and cloud bridge proxies.
Need custom pinouts or proprietary chip variants?
Direct consultation with principal hardware architects and firmware directors
B2B Fast Evaluation
Begin Your Embodied AI Toy Breakthrough
Request engineering datasheets, turnkey BOM quotes, and functional sample kits. Our lead acoustic and hardware architects respond within 24 hours.
