Smart HomeIndustrial Automation
PureAirTech
AI Air Purifier Controller based on Rockchip RK3308
Edge AI air purifier that predicts pollution spikes before they happen.
PM Sensor Accuracy
±3 µg/m³
Fan Noise
24 dB max
PureAirTech
Client
A home appliance brand wanting to differentiate their purifier line with AI-driven preemptive air quality control.
Challenge
Building a cost-effective air purifier controller that can learn pollution patterns (cooking hours, traffic spikes) and pre-activate filtration before air quality degrades.
Product Concept & Architecture
The Rockchip RK3308 quad-core Cortex-A35 SoC was chosen for its Linux capability and rich peripheral set. It reads from a Sensirion SPS30 PM sensor, an SGP40 VOC sensor, and a BME280 temperature/humidity sensor. A PWM-controlled Nidec brushless DC fan provides airflow.
Engineering Solution
We deployed Buildroot Linux with a custom Python/Node.js edge application. A lightweight LSTM model trained on 3 months of household air quality data runs on the RK3308's Cortex-A35 cores. The model predicts PM2.5 levels 30 minutes ahead with 92% accuracy. When a spike is predicted, the fan ramps up preemptively. The device also publishes hourly aggregates to an MQTT dashboard.
Result
User exposure to PM2.5 reduced by 35% compared to reactive auto-mode. Filter life extended 20% through smarter fan scheduling. Total BOM under $45.
Deep Tech FAQ
What makes the AI Air Purifier Controller based on Rockchip RK3308 unique?+
The AI Air Purifier Controller based on Rockchip RK3308 leverages custom hardware and edge AI to deliver industry-leading performance and efficiency.
What are the core technical benefits?+
Key benefits include low power consumption, real-time processing, robust connectivity, and a compact form factor tailored for deployment.
Can this architecture be adapted for other use cases?+
Absolutely. The underlying methodology is modular and can be retargeted for various applications with minimal redesign.
Project Profile
Services Delivered
Hardware DesignEmbedded SoftwareOS Porting
Core Technologies
Embedded LinuxTinyMLWi-Fi/Bluetooth
Silicon & Vendors
RockchipSensirion
